MPO patch cord allows for rapid deployment of multi-port patch field connectivity in high-density Storage Area Network (SAN) and Data Center LAN applications, ensuring efficient use of horizontal and vertical rack pathways through the use of small form factor cable. Built with modular MPO connectivity and LC connectivity, these assemblies provide compatibility, flexibility and system performance in high density LAN/SAN switch Equipment Distribution Area (EDA).

MTP / MPO Push-Pull Connectors for Quick Fiber Optic connections
Push/Pull tab connectors offer maximum accessibility in high density installations; install / remove with one hand
12 times the density of SC style connectors
No need for long fan-out cables or individual long duplex cable runs
High Density design cuts down on installation costs
50/125 OM3 Rated Multimode Fiber, 850nm
Plenum rated jacket
Unique cable ID label for Quality Control and Traceability
Each cable 100% tested for low insertion loss and back reflection
Test data supplied with each cable
Custom lengths available

Cross connected between transmission system or cabinets in telecom room.
Cross connected between cabinets transmission system or in SAN data center.
Cross connected between transmission system and cabinets in iCloud data center and communication room.
